Titan S975 - Dual 5th Gen AMD Epyc Turin CPUs + 8x GPUs Server PC for AI / Deep Learning HPC up to 384 Cores

Home > Workstation Computers > Workstation Computers by CPU > AMD EPYC Workstation Computers > AMD EPYC Genoa 9004 Series - up to 256 Cores Workstation PC >

Titan S975 - Dual 5th Gen AMD Epyc Turin CPUs + 8x GPUs Server PC for AI / Deep Learning HPC up to 384 Cores - SuperMicro 4125GS-TNRT

Alternative Views:

Starting Price: $10,095.00

Availability: Usually Ships in 4 to 6 Weeks
Product Code: S975

Lead Time:

CORE COMPONENTS

Case:

CPU / Processor:

CPU Thermal Compound:

Motherboard:

Memory:

Power:

Operating Systems:

VIDEO & AUDIO

Video Card / GPU 1-2:

Video Card / GPU 3-4:

Sound Card:

Monitor 1:

Monitor 2:

STORAGE

M.2 NVMe Drive 1-2:

SATA Drive 2:

SATA-SAS RAID Controller:

SATA RAID Setup:

CD/DVD:

COMMUNICATIONS

NetWork:

Wireless:

Mouse / Keyboard:

SERVER ACCESSORIES

Mounting Rails:

WARRANTY

Assembly:

TAA Compliance:

Warranty:

Extra Care:

FREE Gift:

Qty:

Technical Specs

Support

Titan S975
Dual 5th Gen AMD Epyc Turin CPUs + 8x GPUs Server PC for AI / Deep Learning HPC up to 384 Cores - SuperMicro 4125GS-TNRT

The S975 is encased in a Supermicro SuperChassis 4U Rackmount Server Chassis, specifically designed for GPU computing. This robust chassis ensures optimal performance, cooling, and reliability even when packed with graphics cards.

Featuring options for Dual AMD EPYC Genoa 9004 or 5th Gen AMD EPYC Turin 9005 processors, the S975 offers a range of configurations, from 32 to 384 cores, depending on the specific model. This allows for incredible flexibility and power to tackle the most intensive computational tasks.

The server supports various DDR5 5600Mhz memory configurations, ranging from 64GB to a staggering 6TB, utilizing 288-Pin DDR5 SDRAM ECC Server Memory. This immense memory capacity is crucial for handling large datasets and complex computations that are typical in GPU workloads.

Equipped with 4x 2000W PSUs in a 2+2 Redundant Power Supplies configuration, the Titan S975 ensures consistent, efficient, and reliable power delivery, essential for high-stakes computing environments. There should be no change that your render or mission-critical calculations should ever be interrupted or lost.

The server supports a range of NVIDIA professional video cards as well as Tesla cars with high-bandwidth memory, providing flexibility to meet different computational and graphical requirements.

The S975 offers various operating system options, including different editions of Microsoft Windows 11, Windows Server, and Linux-based OS choices, catering to different user preferences and requirements.

The Titan S975 is the pinnacle of server technology, designed to deliver exceptional performance for advanced computing tasks in fields such as artificial intelligence, deep learning, and high-performance computing while being backed by our peerless aftermarket support. If you’re serious about parallel computation, the S975 is the server for you.

Default Configuration:

Case: SuperMicro 4125GS-TNRT Rackmount Server Chassis for GPU Computing

Motherboard: Supermicro H13DSG-O-CPU Socket SP5 - Dual AMD Motherboard

Processor: 2x AMD EPYC Genoa 9124 3.0GHz (3.7GHz Turbo) 200W 64MB Cache (32 Cores / 64 Threads)

OS Hard Drive: 1TB M.2 NVMe PCIe 4.0 x4 SSD - read/write 5000/4800 MBps

OS: Windows 11 Professional 64-bit

Memory: 64GB (4 x 16GB) 288-Pin DDR5 4800 ECC Server Memory

Audio: Creative SOUND BLASTERX G1 Up to 24-bit / 96kHz USB Interface Sound Card

Power Supply: 4x 2000W Redundant (2+2) Power Supplies; Titanium Level (96%+)

Video: NVIDIA Quadro T400 4GB GDDR6 Workstation Video Card

Lan: 2x RJ45 10 GBASE-T LAN port(s)

Rear Panel Ports:
- 2 x USB 3.0 Ports
- 2 x RJ45 by 2 x Intel
- 1 x RJ45 Dedicated IPMI LAN port
- 1 x VGA Port ASPEED AST2500

Dimensions:
26.57" x 27" x 41"

Availability:
Usually Ships in 4 to 5 weeks

Product Code:
S975
